Power Designs TP330 Power Supply

I decid­ed to take a gam­ble on pur­chas­ing a Power Designs Inc. TP330 triple out­put pow­er sup­ply. It was a bit rough look­ing with a bunch of stick­ers on the front pan­el, but no scrape marks from past stick­er removal vis­i­ble. The sell­er stat­ed that the bot­tom ana­log meter was non-func­tion­al, but the out­put ter­mi­nals mea­sured volt­age that changed with the volt­age knob.

Power Designs TP330 pow­er sup­ply as received
Continue read­ing “Power Designs TP330 Power Supply”
Posted on

Power Designs D‑series display board update

After the acqui­si­tion of my Power Designs 5015D pow­er sup­ply, I real­ly want­ed to upgrade the dis­play mod­ule so that I had an extra dig­it of res­o­lu­tion. I already had a few ADC/LED meter boards left over from pre­vi­ous projects, but need­ed a dis­play board to pair with it.

Power Designs D‑series dis­play board Rev. 2.4
Continue read­ing “Power Designs D‑series dis­play board update”
Posted on

Power Designs Inc. 5015D power supply cleanup and repair

Repair and cleanup of a Power Designs Inc. 5015D pow­er sup­ply that I pur­chased on Ebay.
This was one of the bet­ter look­ing 5015D pow­er sup­plies that I have seen on Ebay, that was not over­priced or includ­ed an over­priced ship­ping charge. The list­ings con­di­tion descrip­tion said ” ful­ly oper­a­tional and func­tions as intended”.

Power Designs Inc. 5015D front pan­el after cleanup and dis­play mod.
Continue read­ing “Power Designs Inc. 5015D pow­er sup­ply cleanup and repair”
